Size | 35mm*8.2H*32ohm 1mW |
Impedance | 32±15%OHM AT 1000Hz 1.0mW |
F0 | 110±15%Hz AT 1.0mW |
Sensitiity | 117±2.5dB 1mW/1.0KHZ IEC318 |
Listening Test |
SINE WAVE BETWEEN AT 800mV / 50Hz ~5KHz |
Rated Power | 20mW AT 800mV |
Max Short Term Power | 30mW AT 980mV |
THD | MAX2% AT 1mW /179mV/1000HZ |
